Planetary Gear Simulator

Planetary Gear Simulator

Our Planetary Gear Simulator is a special web-based tool we made for allowing visualization of planetary gear systems in motion. Our simulator will show you all the details of planetary gears. The simulator is fun and interactive, making learning easy and exciting.
Become a Member Gear Generator

Wolfrom Planetary Drive

The Wolfrom Planetary Gear, also known as Split Ring Gear, is a type of planetary arrangement that allows for very high reductions in a compact space. This tool allows you to play with the input parameters in order to find a combination that meets the target reduction.
Cycloidal Drive Simulator

Cycloidal Drive Simulator

Design your own cycloidal drive with our Cycloidal Simulator & Generator. Adjust any parameter to meet your specific needs and watch the disc rotate in an interactive animation. When you’re satisfied with the design, download the cycloidal disc as a DXF file. It’s a practical tool for mechanical engineers looking to customize and streamline their projects.
Harmonic Drive Simulator

Harmonic Drive Simulator

Dive into the world of harmonic drives with the first-ever Harmonic Drive Simulator! This unique tool lets you tweak gear settings and watch the magic happen in real-time. See detailed simulations that show you speed ratios, torque ratios, and more with pinpoint accuracy.

Wave Reducer Simulator

Wave reducers with rolling elements are a class of speed reducers that transmit motion through a wave-like profile interacting with intermediate rolling elements, such as balls or rollers. Instead of using gear teeth like planetary or cycloidal drives, they rely on pure rolling contact to achieve high reduction ratios, low backlash, and compact size. The eccentric cam pushes the rolling elements against a specially shaped rigid ring, causing smooth, high-ratio relative motion between input and output.
Harmonic Drive Simulator

gear generator

This online tool simplifies the creation of involute gear profiles. Specify the number of teeth, module, and fine-tune parameters like clearance and backlash. The tool then generates accurate gear profiles based on the input and allows users to download them as DXF files for seamless integration with CAD software.
Planetary Gearbox Design Set Simulator

4-Bar Linkage Simulator

This tool allows you to design and visualize the movement of a classic 4-bar linkage system. Experiment with different link lengths and initial positions. Then watch as the mechanism animates, revealing its unique motion characteristics.

Stack-Up Tolerance Analysis Calculator

Our interactive Tolerance Stack-Up Calculator helps you perform tolerance stack-up calculations efficiently. Input each component dimension along with its tolerance. The tool automatically generates RSS (Root Sum Square) and max-min analyses, updating results in real time as you add or remove rows in the tolerance table.

Planetary Gear Calculator

Design your planetary gear speed reducer with this tool. Input your desired target ratio, add any constraints your design needs to meet, and the algorithm will generate a range of possible combinations that meet your specifications.

Gearbox Designer

[Beta Version] Design, simulate, and export custom gearboxes. This tool offers real-time visualization and instant DXF downloads for your mechanical engineering projects.
