Cycloidal Drive - Ratio 30:1
Cycloidal Drive - Ratio 30:1 - Image 2
Cycloidal Drive - Ratio 30:1 - Image 3
Cycloidal Drive - Ratio 30:1 - Image 4
Cycloidal Drive - Ratio 30:1 - Image 5

Cycloidal Drive – Ratio 30:1

$10.00

  • Design Files for a Cycloidal Drive
  • Fits Nema17 stepper motor
  • Reduction ratio: 30:1
  • STL and STEP files
  • Bill of Materials (BOM)
  • Assembly instructions
  • Note: Members can download this and all other files for free!
Category:

Description

Cycloidal Drive for 3D Printing

  • Fits Nema17 stepper motor
  • Reduction ratio: 30:1
  • STL and STEP files
  • Files for CNC machining included (2D Drawings)
  • Bill of Materials (BOM)
  • Assembly instructions

Note: Members can download this and all other files for free!



🔍 Overview

These are the design files for a Cycloidal Drive for a standard NEMA17 stepper motor.

All hardware components can be sourced from Amazon.

For more details about this design, please check back soon, a YouTube video will be released with the test results of this design.



⚠️ These files are sold as-is, with no warranty. Use at your own risk. No guarantee is made regarding fit, function, or suitability for your application. That said, I’ll do my best to assist with questions or issues if you reach out—your feedback helps improve future versions.
